2/2-way diaphragm isolated high-pressure solenoid valves for high media temperatures - 15 bar , 175°C
Orifice size 1.6 mm for inlet pressures up to 15 bar and media temperatures up to 175°C
Description
These solenoid valves utilize a unique mechanism to absorb dimensional changes of the plastic body due to temperature changes.
No leakage of media at high temperature.
Suitable for applications such as COD measuring devices, also with hot sulfuric acid as a medium.
Specifications
Type
|
2/2-way normally closed
|
Orifice diameter
|
1.6 mm
|
Port Connection
|
M6 | 1/4-28UNF
|
Rated voltage
|
12 VDC | 24 VDC other voltages on request |
Operating pressure range
|
Inlet: 0 - 15 bar Outlet: 0 - 1 bar |
Seal material
|
PTFE
|
Body material
|
PFA
|
Other wetted materials
|
FFKM
|
Fluid temperature range
|
5 - 175°C
|
Ambient temperature range
|
5 - 40°C
|
Power consumption
|
MTV: 17.6 W (inrush voltage), 2.9 W (holding voltage) WTA: 26.3 W (inrush voltage), 4.2 W (holding voltage) |
Operating duration
|
100% ED
|
Mounting direction
|
Any
|
Dimensions
|
MTV: ∅25.3 × 47.7 mm WTA: 25.3 × 28.2 × 54.2 mm |
